Specifications
- Voltage Rated Dc
- 400V
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Genişlik
- 12mm
- Renk
- Green
- Material Flammability Rating
- UL94 V-0
- Number Of Levels
- 1
- ECCN Kodu
- EAR99
- Seri
- COMBICON GMSTBA
- Contact Plating
- Tin
- Number Of Decks
- 1
- Kurşunsuz Kodu
- yes
- Nominal Gerilim
- 400V
- Montaj Tipi
- Through Hole
- Insulation Height
- 0.339 8.61mm
- Safety Approval
- UL
- Terminal Stili
- Solder
- HTS Kodu
- 8536.69.40.40
- Onay Kuruluşu
- CSA, UL
- Number Of Ways
- 7
- Header Orientation
- 90°, Right Angle
- RoHS Durumu
- RoHS Compliant
- Sıra Sayısı
- 1
- Ambalaj
- Bulk
- Voltageiec
- 630V
- Flammability Rating
- UL94 V-0
- Additional Feature
- PA, 94V-0
- Orientation
- Right Angle
- Pitch
- 0.295 7.50mm
- Currentul
- 15A
- Depth
- 12mm
- Gerilim
- 300V
- Number Of Poles
- 7
- Fabrika Tedarik Süresi
- 4 Weeks
- Housing Material
- Polyamide (PA), Nylon
- Contact Tail Length
- 0.138 3.50mm
- Weight
- 1.50003kg
- Parça Durumu
- Active
- Yayın Yılı
- 2010
- Max Current Rating
- 12A
- Montaj
- Through Hole
