Volume pricing
- 1+ pcs$4.68
- 10+ pcs$4.41
- 100+ pcs$4.16
- 500+ pcs$3.93
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 630V
- Connector Type
- Screw, Socket
- Fabrika Tedarik Süresi
- 4 Weeks
- Housing Material
- Polyamide (PA), Nylon
- HTS Kodu
- 8536.69.40.40
- Pozisyon Sayısı
- 12
- Wire Gauge Or Range Awg
- 12-30 AWG
- Kurşunsuz
- Lead Free
- Weight
- 128.999997g
- Max Current Rating
- 12A
- Akım Değeri
- 12A
- Wire Gauge Max
- 12 AWG
- Orientation
- Right Angle
- Terminal
- Screw
- Uzunluk
- 60.96mm
- Contact Plating
- Tin
- Seri
- COMBICON MSTB
- Depth
- 61.8mm
- Additional Feature
- PA, 94V-0
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Özellikler
- Retention Latches (Non-Wire Side), Strain Relief
- Screw Size
- M3
- Montaj
- Free Hanging
- Gerilim
- 300V
- Wire Cross Section
- 2.5 mm2
- ECCN Kodu
- EAR99
- Number Of Ways
- 12
- Flammability Rating
- UL94 V-0
- Tip
- Plug, Female Sockets
- Akım
- 10A
- Max Supply Voltage
- 250V
- Terminal Stili
- Screw - Rising Cage Clamp
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Radyasyon Dayanımı
- No
- Yükseklik
- 60.96mm
- Pitch
- 0.200 5.08mm
- Number Of Levels
- 1
- Sıra Sayısı
- 1
