Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj
- Through Hole
- Number Of Ways
- 8
- Pozisyon Sayısı
- 16
- Number Of Levels
- 2
- Genişlik
- 42.2mm
- Pitch
- 0.200 5.08mm
- Depth
- 22mm
- Number Of Positions Per Level
- 8
- Orientation
- Right Angle
- Kurşunsuz
- Lead Free
- Yükseklik
- 32mm
- Housing Material
- Polyamide (PA), Nylon
- Gerilim
- 300V
- Parça Durumu
- Active
- Voltageiec
- 630V
- Positions Per Level
- 8
- Safety Approval
- CSA; UL
- Max Current Rating
- 10A
- RoHS Durumu
- RoHS Compliant
- Terminal Stili
- Solder
- Number Of Decks
- 2
- Akım
- 15A
- ECCN Kodu
- EAR99
- Akım Değeri
- 10A
- Renk
- Green
- Ambalaj
- Bulk
- Flammability Rating
- UL94 V-0
- Contact Mating Finish
- Tin
- Insulation Height
- 1.122 28.50mm
- Contact Materials
- Copper
- Connector Type
- Plug
- Sıra Sayısı
- 2
- Material Flammability Rating
- UL94 V-0
- Weight
- 161.000004g
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Fabrika Tedarik Süresi
- 4 Weeks
- Yayın Yılı
- 2003
- Seri
- COMBICON MDSTB
- Kurşunsuz Kodu
- yes
- Nominal Gerilim
- 250V
