Specifications
- Voltageiec
- 630V
- Parça Durumu
- Active
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Safety Approval
- UL; VDE; CSA
- RoHS Durumu
- RoHS Compliant
- Screw Size
- M3
- Terminal Stili
- Screw - Rising Cage Clamp
- ECCN Kodu
- EAR99
- Akım
- 15A
- Number Of Decks
- 1
- Material
- Polyamide
- Akım Değeri
- 12A
- Renk
- Green
- Contact Plating
- Tin
- Number Of Poles
- 11
- Stripping Length
- 7mm
- Montaj
- Free Hanging, Plug-In
- Number Of Ways
- 11
- Genişlik
- 55.88mm
- Pitch
- 0.200 5.08mm
- Number Of Levels
- 1
- Wire Gauge Or Range Awg
- 12-30 AWG
- Yükseklik
- 18.3mm
- Housing Material
- Polyamide (PA), Nylon
- Gerilim
- 300V
- Uzunluk
- 15mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Free Hanging (In-Line)
- HTS Kodu
- 8536.69.40.40
- Gender
- Female
- Terminal
- Screw
- Wire Gauge Max
- 12 AWG
- Plug Wire Entry
- 180°
- Ambalaj
- Bulk
- Insulation Height
- 0.591 15.00mm
- Wire Gauge Min
- 24 AWG
- Material Flammability Rating
- UL94 V-0
- Connector Type
- Screw, Socket
- Sıra Sayısı
- 1
- Yayın Yılı
- 2010
