Specifications
- Additional Feature
- STANDARD: UL 94V-0, PA, SAFETY APPROVAL :VDE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Stili
- Solder
- Thickness
- 25.4mm
- Material Flammability Rating
- UL94 V-0
- Gerilim
- 300V
- Akım Değeri
- 12A
- Header Orientation
- 90°, Right Angle
- Genişlik
- 30.48mm
- Uzunluk
- 30.48mm
- Renk
- Green
- Depth
- 12mm
- Pitch
- 0.200 5.08mm
- Number Of Ways
- 6
- Onay Kuruluşu
- CSA, EN, UL, VDE
- Number Of Poles
- 6
- Contact Mating Finish
- Tin
- Weight
- 151.999994g
- Max Current Rating
- 12A
- Voltage Rated Dc
- 320V
- Montaj Tipi
- Through Hole
- Akım
- 15A
- Number Of Levels
- 1
- Yayın Yılı
- 2003
- Flammability Rating
- UL94 V-0
- Pozisyon Sayısı
- 6
- Contact Materials
- Copper, Tin
- Yükseklik
- 12.1mm
- RoHS Durumu
- RoHS Compliant
- Sıra Sayısı
- 1
- Tip
- Header, Male Pins, Shrouded (2 Side)
- Housing Material
- Polyamide (PA), Nylon
- Seri
- COMBICON MSTB
- Number Of Decks
- 1
- Insulation Height
- 0.339 8.61mm
- ECCN Kodu
- EAR99
- Montaj
- Through Hole
- Parça Durumu
- Active
- Nominal Gerilim
- 250V
- Orientation
- Right Angle
