Volume pricing
- 1+ pcs$1.14
- 10+ pcs$1.08
- 100+ pcs$1.02
- 500+ pcs$0.96
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Additional Feature
- STANDARD: UL 94V-0, PA, SAFETY APPROVAL: VDE
- Terminal Stili
- Solder
- Header Orientation
- Vertical
- Genişlik
- 60.96mm
- HTS Kodu
- 8536.69.40.40
- Gerilim
- 300V
- Akım Değeri
- 12A
- Number Of Ways
- 12
- Pitch
- 0.200 5.08mm
- Uzunluk
- 60.96mm
- Renk
- Green
- Depth
- 8.6mm
- Montaj Tipi
- Through Hole
- Voltage Rated Dc
- 250V
- Akım
- 12A
- Contact Mating Finish
- Tin
- Onay Kuruluşu
- CSA, UL
- Number Of Poles
- 12
- Weight
- 153.999996g
- Max Current Rating
- 12A
- Contact Materials
- Copper, Tin
- Yükseklik
- 15.9mm
- Number Of Levels
- 1
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2005
- Insulation Height
- 0.472 12.00mm
- Number Of Decks
- 1
- Tip
- Header, Male Pins, Shrouded (2 Side)
- Sıra Sayısı
- 1
- RoHS Durumu
- RoHS Compliant
- Seri
- COMBICON MSTBV
- Housing Material
- Polyamide (PA), Nylon
- Kurşunsuz Kodu
- yes
- Orientation
- Straight
- ECCN Kodu
- EAR99
- Nominal Gerilim
- 250V
- Montaj
- Through Hole
- Parça Durumu
- Active
