Volume pricing
- 1+ pcs$0.54
- 10+ pcs$0.51
- 100+ pcs$0.48
- 500+ pcs$0.45
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2010
- Flammability Rating
- UL94 V-0
- Number Of Levels
- 1
- Yükseklik
- 15.9mm
- Contact Materials
- Copper, Tin
- Housing Material
- Polyamide (PA), Nylon
- Seri
- COMBICON MSTBV
- RoHS Durumu
- RoHS Compliant
- Tip
- Header, Male Pins, Shrouded (2 Side)
- Sıra Sayısı
- 1
- Number Of Decks
- 1
- Insulation Height
- 0.472 12.00mm
- Parça Durumu
- Active
- Montaj
- Through Hole
- Nominal Gerilim
- 250V
- ECCN Kodu
- EAR99
- Orientation
- Straight
- Kurşunsuz Kodu
- yes
- Contact Tail Length
- 0.154 3.90mm
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Safety Approval
- UL
- Fabrika Tedarik Süresi
- 4 Weeks
- Voltageiec
- 400V
- Terminal Stili
- Solder
- Additional Feature
- PBT, 94V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Flammability Rating
- UL94 V-0
- Thickness
- 25.4mm
- Akım Değeri
- 12A
- Gerilim
- 300V
- Genişlik
- 30.48mm
- Header Orientation
- Vertical
- Renk
- Green
- Depth
- 8.6mm
- Uzunluk
- 30.48mm
- Pitch
- 0.200 5.08mm
- Number Of Ways
- 6
- Max Current Rating
- 12A
- Weight
- 153.999996g
