Specifications
- Pozisyon Sayısı
- 2
- Insulation Height
- 0.339 8.61mm
- Contact Plating
- Tin
- Additional Feature
- STANDARD: UL 94V-0, PA, SAFETY APPROVAL :VDE
- Weight
- 152.999995g
- Fabrika Tedarik Süresi
- 7 Weeks
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -40°C
- Terminal Stili
- Solder
- HTS Kodu
- 8536.69.40.40
- Number Of Levels
- 1
- Montaj
- Through Hole
- Akım Değeri
- 12A
- Reach Svhc
- No SVHC
- Yayın Yılı
- 2001
- Fastening Method
- CONNECTOR
- Seri
- COMBICON MSTBA
- Yükseklik
- 12.08mm
- Parça Durumu
- Active
- Max Current Rating
- 12A
- Nominal Gerilim
- 250V
- Number Of Decks
- 1
- Contact Tail Length
- 0.138 3.50mm
- ECCN Kodu
- EAR99
- Housing Material
- Polyamide (PA), Nylon
- Genişlik
- 12.1mm
- Onay Kuruluşu
- CSA, EN, UL, VDE
- Voltageiec
- 400V
- Gerilim
- 300V
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Kurşunsuz Kodu
- yes
- Header Orientation
- 90°, Right Angle
- Uzunluk
- 12.16mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flammability Rating
- UL94 V-0
- Depth
- 12mm
- Sıra Sayısı
- 1
- Renk
- Green
- Thickness
- 5.08mm
- Akım
- 15A
