Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Tip
- Plug, Female Sockets
- Uzunluk
- 60.96mm
- Voltageiec
- 630V
- Gerilim
- 300V
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Genişlik
- 60.96mm
- ECCN Kodu
- EAR99
- Voltage Rated Ac
- 250V
- Housing Material
- Polyamide (PA), Nylon
- Number Of Contacts
- 12
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Stripping Length
- 7mm
- Number Of Decks
- 1
- Nominal Gerilim
- 250V
- Max Supply Voltage
- 250V
- Max Current Rating
- 12A
- Pitch
- 0.200 5.08mm
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Free Hanging (In-Line)
- Material Flammability Rating
- UL94 V-0
- Safety Approval
- UL
- Lead Pitch
- 5.08mm
- Ambalaj
- Bulk
- Connector Type
- Screw, Socket
- Özellikler
- Retention Latches (Non-Wire Side)
- Number Of Ways
- 12
- Orientation
- Right Angle
- Akım
- 15A
- Wire Gauge Min
- 12 AWG
- Gender
- Female
- Renk
- Green
- Depth
- 18.2mm
- Flammability Rating
- UL94 V-0
- Sıra Sayısı
- 1
- Wire Cross Section
- 2.5 mm2
- Terminal
- Screw
- Wire Gauge Max
- 30 AWG
- Terminal Stili
- Screw - Rising Cage Clamp
