Volume pricing
- 1+ pcs$1.45
- 10+ pcs$1.37
- 100+ pcs$1.29
- 500+ pcs$1.22
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Sıra Sayısı
- 1
- Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 12 AWG
- Akım
- 15A
- Orientation
- Right Angle
- Renk
- Black
- Ambalaj
- Bulk
- Number Of Ways
- 4
- Özellikler
- Retention Latches (Non-Wire Side)
- Connector Type
- Screw, Socket
- Pitch
- 0.197 5.00mm
- Material Flammability Rating
- UL94 V-0
- Safety Approval
- UL; CSA
- Montaj Tipi
- Free Hanging (In-Line)
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 250V
- Number Of Decks
- 1
- Wire Strip Length
- 7mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Max Supply Voltage
- 250V
- Max Current Rating
- 12A
- Genişlik
- 20mm
- Number Of Contacts
- 4
- Housing Material
- Polyamide (PA), Nylon
- ECCN Kodu
- EAR99
- Gerilim
- 300V
- Voltageiec
- 630V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 15mm
- Tip
- Plug, Female Sockets
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 12A
- Number Of Levels
- 1
- Montaj
- Cable, Free Hanging
- Plug Wire Entry
- 180°
- Radyasyon Dayanımı
- No
- Yayın Yılı
- 2011
- Screw Size
- M3
- Parça Durumu
- Active
- Seri
- COMBICON MSTB
