Volume pricing
- 1+ pcs$2.13
- 10+ pcs$2.01
- 100+ pcs$1.90
- 500+ pcs$1.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Safety Approval
- UL
- Wire Gauge Max
- 12 AWG
- Montaj Tipi
- Free Hanging (In-Line)
- RoHS Durumu
- RoHS Compliant
- Material Flammability Rating
- UL94 V-0
- Akım Değeri
- 16A
- Montaj
- Free Hanging
- Akım
- 16A
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Height
- 0.689 17.50mm
- Kurşunsuz Kodu
- yes
- Pitch
- 0.300 7.62mm
- Housing Material
- Polyamide (PA), Nylon
- Gerilim
- 600V
- Yayın Yılı
- 2011
- Flammability Rating
- UL94 V-0
- Connector Type
- Screw
- Terminal Stili
- Screw - Rising Cage Clamp
- Parça Durumu
- Active
- Tip
- Plug, Male Pins
- Weight
- 4.449996g
- Renk
- Green
- HTS Kodu
- 8536.69.40.40
- Ambalaj
- Bulk
- Nominal Gerilim
- 1kV
- REACH Uyumluluk Kodu
- unknown
- Number Of Levels
- 1
- Wire Gauge Min
- 24 AWG
- Sıra Sayısı
- 1
- Screw Size
- M3
- Number Of Ways
- 2
- Seri
- COMBICON GIC
- Additional Feature
- PA, UL 94V0
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Wire Strip Length
- 8mm
- Voltageiec
- 1kV
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Gauge Or Range Awg
- 12-30 AWG
- Pozisyon Sayısı
- 2
