Volume pricing
- 1+ pcs$2.64
- 10+ pcs$2.49
- 100+ pcs$2.35
- 500+ pcs$2.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Current Rating
- 22A
- Montaj Tipi
- Through Hole
- Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 26 AWG
- ECCN Kodu
- EAR99
- Radyasyon Dayanımı
- No
- Housing Material
- Polyamide (PA), Nylon
- Wire Termination
- Screw - Rising Cage Clamp
- Number Of Contacts
- 5
- Terminal
- Solder
- Number Of Ways
- 5
- Akım Değeri
- 17.5A
- Gerilim
- 300V
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Kurşunsuz Kodu
- yes
- Depth
- 13.4mm
- Nominal Gerilim
- 400V
- Number Of Levels
- 1
- Safety Approval
- UL
- Ambalaj
- Bulk
- Renk
- Green
- Weight
- 7.700014g
- Mating Orientation
- 35° (145°) Angle with Board
- Parça Durumu
- Active
- Akım
- 15A
- Max Supply Voltage
- 250V
- Wire Gauge Min
- 14 AWG
- Screw Thread
- M3
- Pitch
- 0.200 5.08mm
- Kurşunsuz
- Lead Free
- Connector Type
- Screw
- Contact Materials
- Tin
- Seri
- COMBICON SMKDSP
- Additional Feature
- PA, 94V-0
- Yükseklik
- 18.8mm
- Wire Gauge
- 14-30 AWG
- Yayın Yılı
- 2011
- Uzunluk
- 13.4mm
- Sıra Sayısı
- 1
- Montaj
- Through Hole
