Volume pricing
- 1+ pcs$1.18
- 10+ pcs$1.11
- 100+ pcs$1.05
- 500+ pcs$0.99
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yükseklik
- 18.8mm
- Wire Gauge
- 14-30 AWG
- Yayın Yılı
- 2001
- Uzunluk
- 13.4mm
- Contact Materials
- Tin
- Lead Pitch
- 5.08mm
- Seri
- COMBICON SMKDSP
- Pitch
- 0.200 5.08mm
- Kurşunsuz
- Lead Free
- Connector Type
- Screw
- Voltage Rated Ac
- 250V
- Screw Thread
- M3
- RoHS Durumu
- RoHS Compliant
- Özellikler
- Interlocking (Side)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 7 Weeks
- Genişlik
- 20.32mm
- Number Of Decks
- 1
- Reach Svhc
- No SVHC
- Wirecable Gauge
- 26 AWG
- Sıra Sayısı
- 1
- Montaj
- Through Hole
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Kurşunsuz Kodu
- yes
- Number Of Contacts
- 4
- Wire Termination
- Screw - Rising Cage Clamp
- Akım Değeri
- 17.5A
- Number Of Ways
- 4
- Gerilim
- 300V
- Housing Material
- Polyamide (PA), Nylon
- Max Current Rating
- 22A
- Montaj Tipi
- Through Hole
- Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 30 AWG
- ECCN Kodu
- EAR99
- Radyasyon Dayanımı
- No
- Mating Orientation
- 35° (145°) Angle with Board
- Parça Durumu
- Active
- Akım
- 15A
- Max Supply Voltage
- 250V
