Volume pricing
- 1+ pcs$0.72
- 10+ pcs$0.68
- 100+ pcs$0.64
- 500+ pcs$0.60
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Materials
- Tin
- Seri
- COMBICON MKKDSNH
- Wire Gauge
- 14-30 AWG
- Yükseklik
- 10.16mm
- Additional Feature
- POLYAMIDE, 94V-0
- Yayın Yılı
- 2011
- Uzunluk
- 8.6mm
- Screw Thread
- M3
- Kurşunsuz
- Lead Free
- Pitch
- 0.200 5.08mm
- Connector Type
- Screw
- RoHS Durumu
- RoHS Compliant
- Özellikler
- High Wire Entry Level, Interlocking (Side)
- Montaj
- Through Hole
- Genişlik
- 22.6mm
- Number Of Decks
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 7 Weeks
- Number Of Contacts
- 2
- Wire Termination
- Screw - Rising Cage Clamp
- Gerilim
- 300V
- Number Of Ways
- 2
- Akım Değeri
- 13.5A
- Kurşunsuz Kodu
- yes
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Montaj Tipi
- Through Hole
- Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 30 AWG
- Max Current Rating
- 13.5A
- ECCN Kodu
- EAR99
- Housing Material
- Polyamide (PA), Nylon
- Weight
- 28.349523g
- Parça Durumu
- Active
- HTS Kodu
- 8536.69.40.40
- Mating Orientation
- Horizontal with Board
- Wire Gauge Min
- 26 AWG
- Akım
- 10A
- Orientation
- Straight
- Nominal Gerilim
- 400V
- Safety Approval
- UL; CSA
