Volume pricing
- 1+ pcs$0.81
- 10+ pcs$0.76
- 100+ pcs$0.72
- 500+ pcs$0.68
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Connector Type
- Screw
- Screw Thread
- M2
- Mating Orientation
- 55° (125°) Angle with Board
- ECCN Kodu
- EAR99
- Number Of Contacts
- 3
- Number Of Decks
- 1
- Contact Plating
- Tin
- Number Of Levels
- 1
- Wire Gauge Min
- 26 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pitch
- 0.150 3.81mm
- Max Current Rating
- 12A
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Number Of Ways
- 3
- Uzunluk
- 10mm
- Fabrika Tedarik Süresi
- 7 Weeks
- REACH Uyumluluk Kodu
- not_compliant
- Kurşunsuz Kodu
- yes
- Wire Gauge Max
- 30 AWG
- Safety Approval
- CB; CCA; CSA; CUL; GOST; UL
- Yükseklik
- 11.42mm
- Wire Gauge
- 16-30 AWG
- Additional Feature
- PA, 94V-0
- Genişlik
- 13mm
- Yayın Yılı
- 2010
- Renk
- Green
- Housing Material
- Polyamide (PA), Nylon
- Nominal Gerilim
- 200V
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- Copper
- Akım Değeri
- 10A
- Flammability Rating
- UL94 V-0
- Montaj
- Through Hole
- Kurşunsuz
- Lead Free
- Weight
- 1.941999g
- Montaj Tipi
- Through Hole
- Wire Termination
- Screw - Rising Cage Clamp
- Sıra Sayısı
- 1
- Gerilim
- 300V
- Parça Durumu
- Active
