Volume pricing
- 1+ pcs$0.91
- 10+ pcs$0.86
- 100+ pcs$0.81
- 500+ pcs$0.77
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Ac
- 250V
- Wire Gauge
- 14-30 AWG
- Maks. Çalışma Sıcaklığı
- 100°C
- Number Of Decks
- 2
- Max Current Rating
- 13.5A
- RoHS Durumu
- RoHS Compliant
- Number Of Levels
- 2
- Seri
- COMBICON MKKDSN
- Radyasyon Dayanımı
- No
- Montaj Tipi
- Through Hole
- Genişlik
- 19.1mm
- Kurşunsuz Kodu
- yes
- Renk
- Green
- Number Of Ways
- 3
- Min. Çalışma Sıcaklığı
- -20°C
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 18.3mm
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2001
- Max Supply Voltage
- 250V
- Gerilim
- 300V
- Kurşunsuz
- Lead Free
- Özellikler
- Interlocking (Side)
- Wire Gauge Max
- 26 AWG
- Weight
- 28.349523g
- Contact Materials
- Tin
- Flammability Rating
- UL94 V-0
- Orientation
- Straight
- Screw Thread
- M3
- Test Voltage
- 4kV
- Akım
- 10A
- Yükseklik
- 18.3mm
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Wire Gauge Min
- 14 AWG
- Wire Termination
- Screw - Rising Cage Clamp
- Housing Material
- Polyamide (PA), Nylon
- Lead Pitch
- 5.08mm
- Akım Değeri
- 13.5A
- Mating Orientation
- Horizontal with Board
