Volume pricing
- 1+ pcs$3.51
- 10+ pcs$3.31
- 100+ pcs$3.12
- 500+ pcs$2.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- REACH Uyumluluk Kodu
- unknown
- Screw Size
- M3
- Terminal Stili
- Screw - Rising Cage Clamp
- Pitch
- 0.200 5.08mm
- Wire Strip Length
- 7mm
- Contact Mating Finish
- Tin
- Weight
- 6.930013g
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Ways
- 2
- Wire Gauge Or Range Awg
- 12-30 AWG
- Akım
- 12A
- Seri
- COMBICON TVMSTB
- Currentul
- 10A
- Additional Feature
- PA, 94V-0
- Material Flammability Rating
- UL94 V-0
- Number Of Levels
- 1 (Mate), 2 (Input)
- Insulation Height
- 1.016 25.81mm
- Gerilim
- 250V
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Sıra Sayısı
- 1
- Pozisyon Sayısı
- 2
- Montaj Tipi
- Free Hanging (In-Line)
- RoHS Durumu
- RoHS Compliant
- Number Of Decks
- 1
- Wire Gauge Max
- 24 AWG
- Akım Değeri
- 12A
- Özellikler
- Retention Latches
- Plug Wire Entry
- 90° and 270°
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 250V
- Ambalaj
- Bulk
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Parça Durumu
- Active
- HTS Kodu
- 8536.69.40.40
- Positions Per Level
- 2 (Mate), 4 (Input)
- Fabrika Tedarik Süresi
- 4 Weeks
- Montaj
- Free Hanging
- Housing Material
- Polyamide (PA), Nylon
- Tip
- Plug, Female Sockets
