Volume pricing
- 1+ pcs$23.09
- 10+ pcs$21.78
- 100+ pcs$20.55
- 500+ pcs$19.39
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pitch
- 0.400 10.16mm
- Wire Gauge Or Range Mm
- 0.75-16mm2
- RoHS Durumu
- RoHS Compliant
- Flammability Rating
- UL94 V-0
- Tip
- Plug, Female Sockets
- Wire Strip Length
- 18mm
- Currentiec
- 76A
- Number Of Decks
- 1
- Akım
- 60A
- Insulation Height
- 2.024 51.40mm
- Connector Type
- Screw
- Ambalaj
- Bulk
- Montaj Tipi
- Free Hanging (In-Line)
- Screw Size
- M4
- Material Flammability Rating
- UL94 V-0
- Safety Approval
- UL
- Wire Cross Section
- 16 mm2
- Akım Değeri
- 76A
- Gerilim
- 600V
- Yayın Yılı
- 2011
- Terminal Stili
- Screw - Rising Cage Clamp
- Seri
- COMBICON TPC
- Kurşunsuz Kodu
- yes
- Wire Gauge Min
- 18 AWG
- Weight
- 453.59237g
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 5
- Nominal Gerilim
- 1kV
- Parça Durumu
- Active
- Wire Gauge Or Range Awg
- 4-20 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 12 Weeks
- Positions Per Level
- 5 (Mate), 10 (Input)
- Material
- Polyamide, Silver
- Additional Feature
- PA, UL 94V-0
- Contact Mating Finish
- Silver
- Number Of Ways
- 5
- Plug Wire Entry
- 180°
- ECCN Kodu
- EAR99
- Wire Gauge Max
- 6 AWG
