Specifications
- Stripping Length
- 7mm
- Gender
- Male
- RoHS Durumu
- RoHS Compliant
- Number Of Contacts
- 4
- Weight
- 5.74401g
- Connector Type
- Screw
- Kurşunsuz
- Lead Free
- ECCN Kodu
- EAR99
- Pitch
- 0.197 5.00mm
- Genişlik
- 20mm
- Flammability Rating
- UL94 V-0
- Yükseklik
- 17.3mm
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 1
- Parça Durumu
- Active
- Akım
- 15A
- Nominal Gerilim
- 400V
- Insulation Materials
- Nylon
- Wire Termination
- Screw - Rising Cage Clamp
- Seri
- COMBICON MKDS
- Material
- Polyamide
- Housing Material
- Polyamide (PA), Nylon
- Akım Değeri
- 17.5A
- Ambalaj
- Bulk
- Wire Gauge Max
- 30 AWG
- Montaj Tipi
- Through Hole
- Min. Çalışma Sıcaklığı
- -20°C
- Onay Kuruluşu
- CSA, UL, cULus
- Test Voltage
- 4kV
- Wire Gauge
- 14-30 AWG
- Maks. Çalışma Sıcaklığı
- 100°C
- Montaj
- Through Hole
- Wire Gauge Min
- 14 AWG
- Özellikler
- Interlocking (Side)
- Yayın Yılı
- 2008
- Max Current Rating
- 22A
- Screw Thread
- M3
- Mating Orientation
- Horizontal with Board
- Fabrika Tedarik Süresi
- 4 Weeks
- Gerilim
- 300V
