Volume pricing
- 1+ pcs$1.26
- 10+ pcs$1.19
- 100+ pcs$1.12
- 500+ pcs$1.06
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Number Of Poles
- 3
- Number Of Circuits
- 3
- Sıra Sayısı
- 1
- Nominal Gerilim
- 690V
- Akım
- 30A
- Seri
- COMBICON MKDS
- Depth
- 12.5mm
- Wire Termination
- Screw - Rising Cage Clamp
- Insulation Materials
- Nylon
- Pozisyon Sayısı
- 3
- Max Supply Voltage
- 690V
- Material
- Polyamide
- Pin Sayısı
- 3
- RoHS Durumu
- RoHS Compliant
- Gender
- Male
- Stripping Length
- 8mm
- Connector Type
- PCB, Terminal Block
- Weight
- 9.530004g
- Number Of Contacts
- 3
- Housing Color
- Green
- Kurşunsuz
- Lead Free
- Voltage Rated Ac
- 500V
- Flammability Rating
- UL94 V-0
- Yükseklik
- 21.7mm
- Genişlik
- 12.5mm
- Pitch
- 0.375 9.53mm
- Terminal
- Screw
- Gerilim
- 600V
- Fabrika Tedarik Süresi
- 7 Weeks
- Mating Orientation
- Horizontal with Board
- Screw Thread
- M3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Number Of Positions Per Level
- 3
- Uzunluk
- 28.52mm
- Lead Pitch
- 9.5mm
- Number Of Levels
- 1
- Contact Materials
- Tin
- Renk
- Green
