Volume pricing
- 1+ pcs$6.42
- 10+ pcs$6.06
- 100+ pcs$5.71
- 500+ pcs$5.39
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Free Hanging (In-Line)
- Connector Type
- Screw
- Screw Size
- M3
- Voltageiec
- 1kV
- Plug Wire Entry
- 180°
- Akım Değeri
- 16A
- Housing Material
- Polyamide (PA), Nylon
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Max
- 12 AWG
- Ambalaj
- Bulk
- Montaj
- Free Hanging
- Pitch
- 0.300 7.62mm
- Wire Strip Length
- 8mm
- Wire Gauge Min
- 24 AWG
- Özellikler
- Retention Latches (Non-Wire Side)
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2011
- Tip
- Plug, Female Sockets
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Currentiec
- 16A
- ECCN Kodu
- EAR99
- Akım
- 18.5A
- Number Of Levels
- 1
- Safety Approval
- UL
- Insulation Height
- 0.689 17.50mm
- Nominal Gerilim
- 1kV
- Number Of Ways
- 8
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 1
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 12-30 AWG
- Gerilim
- 600V
- Fabrika Tedarik Süresi
- 4 Weeks
- Parça Durumu
- Active
- Wire Cross Section
- 2.5 mm2
- Contact Mating Finish
- Tin
- Renk
- Green
- Terminal Stili
- Screw - Rising Cage Clamp
- Pozisyon Sayısı
- 8
