Volume pricing
- 1+ pcs$16.86
- 10+ pcs$15.90
- 100+ pcs$15.00
- 500+ pcs$14.15
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nominal Gerilim
- 200V
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 1
- Pozisyon Sayısı
- 12
- Additional Feature
- PA, 94V-0
- Max Supply Voltage
- 160V
- Material
- Polyamide
- Seri
- COMBICON MKKDS
- Depth
- 16.3mm
- Wire Termination
- Screw - Rising Cage Clamp
- Insulation Materials
- Nylon
- Number Of Contacts
- 24
- Weight
- 907.18474g
- Connector Type
- Screw
- RoHS Durumu
- RoHS Compliant
- Gender
- Male
- Stripping Length
- 5mm
- Yükseklik
- 16.2mm
- Flammability Rating
- UL94 V-0
- Genişlik
- 47.62mm
- Pitch
- 0.150 3.81mm
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
- Number Of Ways
- 12
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Uzunluk
- 47.67mm
- Safety Approval
- UL
- Number Of Levels
- 2
- Gerilim
- 300V
- HTS Kodu
- 8536.69.40.40
- Fabrika Tedarik Süresi
- 4 Weeks
- Mating Orientation
- Horizontal with Board
- Screw Thread
- M2
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Renk
- Green
- Contact Materials
- Tin
- Number Of Decks
- 1
- Radyasyon Dayanımı
- No
