Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8536.69.40.40
- Depth
- 16.9mm
- Flammability Rating
- UL94 V-0
- Max Current Rating
- 16A
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Safety Approval
- UL; CSA
- Yayın Yılı
- 2008
- Renk
- Green
- Gerilim
- 300V
- Housing Material
- Polyamide (PA), Nylon
- Gender
- Male
- Weight
- 60.000008g
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Materials
- Nylon
- Wire Gauge Min
- 24 AWG
- Parça Durumu
- Active
- Montaj
- Through Hole
- Wire Cross Section
- 2.5 mm2
- Genişlik
- 14.2mm
- Material
- Polyamide
- Onay Kuruluşu
- CB, CSA, KEMA, UL, cULus
- Özellikler
- Interlocking (Side)
- Pitch
- 5.08mm
- Kurşunsuz Kodu
- yes
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Wire Gauge
- 12-26 AWG
- Uzunluk
- 5.08mm
- Max Supply Voltage
- 250V
- Mating Orientation
- 45° (135°) Angle with Board
- Wire Termination
- Screwless - Spring Cage, Tension Clamp
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 7 Weeks
- Nominal Gerilim
- 400V
- Akım
- 10A
- Number Of Ways
- 1
- Stripping Length
- 7.5mm
- Number Of Contacts
- 1
- Seri
- COMBICON ZFKDS
