Volume pricing
- 1+ pcs$2.85
- 10+ pcs$2.68
- 100+ pcs$2.53
- 500+ pcs$2.39
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal
- IDC
- Housing Material
- Polyamide (PA), Nylon
- Wire Gauge Max
- 26 AWG
- Max Current Rating
- 5A
- Montaj Tipi
- Through Hole
- Nominal Gerilim
- 160V
- Number Of Decks
- 1
- Gerilim
- 300V
- Max Supply Voltage
- 160V
- Kurşunsuz
- Lead Free
- Lead Pitch
- 3.81mm
- Genişlik
- 10mm
- Akım Değeri
- 5A
- Orientation
- Straight
- Montaj
- Through Hole
- RoHS Durumu
- RoHS Compliant
- Safety Approval
- UL; CSA
- Kurşunsuz Kodu
- yes
- Number Of Contacts
- 5
- Wire Cross Section
- 0.34 mm2
- Wire Gauge Min
- 22 AWG
- Ambalaj
- Bulk
- Wire Gauge
- 22-28 AWG
- Material
- Polyamide
- Thickness
- 15.24mm
- Uzunluk
- 20.24mm
- Mating Orientation
- Horizontal with Board
- Pitch
- 0.150 3.81mm
- ECCN Kodu
- EAR99
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Number Of Levels
- 1
- Seri
- COMBICON IDC
- Weight
- 70.999992g
- Wire Termination
- Screwless - IDC
- Fabrika Tedarik Süresi
- 4 Weeks
- Depth
- 12.4mm
- Yayın Yılı
- 2010
- Flammability Rating
- UL94 V-0
- Insulation Materials
- Nylon
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
