Volume pricing
- 1+ pcs$0.52
- 10+ pcs$0.49
- 100+ pcs$0.46
- 500+ pcs$0.44
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Gender
- Male
- Renk
- Green
- Fabrika Tedarik Süresi
- 4 Weeks
- Terminal
- Solder
- Fastening Method
- SPRING LOADED
- Weight
- 61.000009g
- ECCN Kodu
- EAR99
- Akım
- 10A
- Parça Durumu
- Active
- Wire Gauge
- 12-26 AWG
- Özellikler
- Interlocking (Side)
- Flammability Rating
- UL94 V-0
- Wire Cross Section
- 2.5 mm2
- Montaj
- Through Hole
- Max Supply Voltage
- 250V
- Wire Termination
- Screwless - Spring Cage, Tension Clamp
- Housing Material
- Polyamide (PA), Nylon
- Akım Değeri
- 12A
- Number Of Decks
- 3
- Pitch
- 5.08mm
- Orientation
- Right Angle
- Kurşunsuz
- Lead Free
- Seri
- COMBICON ZFK3DS
- Number Of Ways
- 1
- Mating Orientation
- 45° (135°) Angle with Board
- Wire Gauge Max
- 26 AWG
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Kurşunsuz Kodu
- yes
- Number Of Levels
- 3
- Nominal Gerilim
- 400V
- Wire Gauge Min
- 12 AWG
- Depth
- 32.2mm
- Sıra Sayısı
- 3
- Pozisyon Sayısı
- 1
- Material
- Polyamide
- Uzunluk
- 5.08mm
- RoHS Durumu
- RoHS Compliant
- Safety Approval
- UL; CSA
- Max Current Rating
- 12A
