Volume pricing
- 1+ pcs$2.45
- 10+ pcs$2.31
- 100+ pcs$2.18
- 500+ pcs$2.06
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Gender
- Female
- Yayın Yılı
- 2011
- Nominal Gerilim
- 250V
- Orientation
- Straight
- Number Of Contacts
- 1
- Additional Feature
- PA, UL 94V-0, SAFETY APPROVAL: GL; RS; UL
- Montaj
- Through Hole
- Özellikler
- Feed Through, Interlocking (Side)
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- HTS Kodu
- 8536.90.40.00
- Wire Gauge Max
- 24 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mating Orientation
- Horizontal with Board
- Safety Approval
- CCA; CSA; CUL; EAC; SEV
- Weight
- 17.060006g
- Contact Materials
- Copper, Tin
- Montaj Tipi
- Through Hole
- Housing Material
- Polyamide (PA), Nylon
- Pitch
- 10mm
- Screw Thread
- M4
- RoHS Durumu
- RoHS Compliant
- Gerilim
- 600V
- Yükseklik
- 28.7mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Max Current Rating
- 76A
- ECCN Kodu
- EAR99
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Flammability Rating
- UL94 V-0
- Seri
- COMBICON KDS
- Akım Değeri
- 57A
- Number Of Ways
- 1
- Wire Gauge Min
- 6 AWG
- Number Of Decks
- 1
- Renk
- Green
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Sıra Sayısı
- 1
- Wire Gauge
- 6-24 AWG
- Genişlik
- 36.8mm
