Volume pricing
- 1+ pcs$12.06
- 10+ pcs$11.37
- 100+ pcs$10.73
- 500+ pcs$10.12
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pitch
- 0.400 10.16mm
- RoHS Durumu
- RoHS Compliant
- Gerilim
- 600V
- Fabrika Tedarik Süresi
- 4 Weeks
- ECCN Kodu
- EAR99
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Nominal Gerilim
- 1kV
- Yayın Yılı
- 1998
- Additional Feature
- PA, UL 94V-0
- Özellikler
- Threaded Mating Lock, Shield Connection Front Side
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- HTS Kodu
- 8536.69.40.40
- Wire Gauge Max
- 20 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pozisyon Sayısı
- 2
- Safety Approval
- UL
- Front Panel Wire Connection
- Header, Female Sockets
- Contact Materials
- Silver
- Elv
- Compliant
- Rear Panel Wire Connection
- Bolt/Screw Clamp - Wire Entry Parallel to Panel
- Panel Mount Type
- 2 Piece, Snap Lock - Front Flange
- Sıra Sayısı
- 1
- Wire Gauge
- 6-20 AWG
- Genişlik
- 2.417 61.40mm
- Akım
- 55A
- REACH Uyumluluk Kodu
- unknown
- Terminal
- Screw
- Flammability Rating
- UL94 V-0
- Seri
- COMBICON DFK-IPC
- Panel Thickness
- 0.039 ~ 0.118 1.0 ~ 3.0mm
- Akım Değeri
- 76A
- Number Of Ways
- 2
- Wire Gauge Min
- 6 AWG
- Number Of Levels
- 1
- Renk
- Green
- Number Of Decks
- 1
- Kurşunsuz
- Not Applicable
