Volume pricing
- 1+ pcs$36.44
- 10+ pcs$34.38
- 100+ pcs$32.43
- 500+ pcs$30.60
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Front Panel Wire Connection
- Header, Male Pins
- Contact Plating
- Silver
- Wire Gauge Max
- 20 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Safety Approval
- UL
- HTS Kodu
- 8536.69.40.40
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Özellikler
- Threaded Mating Lock, Shield Connection Front Side
- Additional Feature
- PA, UL 94V-0
- Nominal Gerilim
- 1kV
- Yayın Yılı
- 1998
- ECCN Kodu
- EAR99
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Fabrika Tedarik Süresi
- 7 Weeks
- Gerilim
- 600V
- RoHS Durumu
- RoHS Compliant
- Pitch
- 0.400 10.16mm
- Renk
- Green
- Number Of Decks
- 1
- Number Of Ways
- 7
- Number Of Positions Per Level
- 7
- Number Of Levels
- 1
- Wire Gauge Min
- 6 AWG
- Akım Değeri
- 76A
- Seri
- COMBICON DFK-PC
- Flammability Rating
- UL94 V-0
- Panel Thickness
- 0.039 ~ 0.118 1.0 ~ 3.0mm
- REACH Uyumluluk Kodu
- unknown
- Genişlik
- 4.192 106.48mm
- Akım
- 55A
- Wire Gauge
- 6-20 AWG
- Sıra Sayısı
- 1
- Panel Mount Type
- 2 Piece, Snap Lock - Front Flange
- Rear Panel Wire Connection
- Bolt/Screw Clamp - Wire Entry Parallel to Panel
