Volume pricing
- 1+ pcs$29.05
- 10+ pcs$27.41
- 100+ pcs$25.86
- 500+ pcs$24.39
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Additional Feature
- PA, UL 94V-0
- Orientation
- Straight
- Yayın Yılı
- 1998
- Nominal Gerilim
- 1kV
- Gender
- Male
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Montaj
- Through Hole
- Özellikler
- Threaded Mating Lock, Shield Connection Front Side
- Contact Plating
- Silver
- Front Panel Wire Connection
- Header, Male Pins
- Weight
- 179.999996g
- Pozisyon Sayısı
- 5
- Depth
- 30.55mm
- Safety Approval
- UL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Max
- 20 AWG
- Pitch
- 0.400 10.16mm
- Gerilim
- 600V
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 4 Weeks
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Material
- Polyamide
- ECCN Kodu
- EAR99
- Stripping Length
- 12mm
- Akım Değeri
- 76A
- Panel Thickness
- 0.039 ~ 0.118 1.0 ~ 3.0mm
- Flammability Rating
- UL94 V-0
- Seri
- COMBICON DFK-PC
- Onay Kuruluşu
- CB, UL
- Number Of Decks
- 1
- Renk
- Green
- Number Of Levels
- 1
- Wire Gauge Min
- 6 AWG
- Number Of Ways
- 5
- Kurşunsuz
- Lead Free
- Rear Panel Wire Connection
- Bolt/Screw Clamp - Wire Entry Parallel to Panel
- Sıra Sayısı
- 1
- Panel Mount Type
- 2 Piece, Snap Lock - Front Flange
- Akım
- 55A
