Volume pricing
- 1+ pcs$16.93
- 10+ pcs$15.97
- 100+ pcs$15.07
- 500+ pcs$14.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Safety Approval
- UL
- Contact Materials
- Silver
- Number Of Levels
- 1
- Rear Panel Wire Connection
- PCB Pins - Right Angle
- Akım Değeri
- 76A
- Weight
- 21.640013g
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Renk
- Green
- Pozisyon Sayısı
- 3
- Parça Durumu
- Active
- Seri
- COMBICON DFK-IPC
- Panel Thickness
- 0.039 ~ 0.118 1.0 ~ 3.0mm
- Number Of Ways
- 3
- Orientation
- Right Angle
- Yayın Yılı
- 2011
- Panel Mount Type
- 2 Piece, Snap Lock - Front Flange
- Nominal Gerilim
- 1kV
- Genişlik
- 2.817 71.56mm
- Gerilim
- 600V
- Pitch
- 0.400 10.16mm
- Additional Feature
- PA, UL 94V-0
- Sıra Sayısı
- 1
- Fabrika Tedarik Süresi
- 7 Weeks
- Max Current Rating
- 76A
- Uzunluk
- 71.56mm
- Gender
- Female
- Flammability Rating
- UL94 V-0
- ECCN Kodu
- EAR99
- Özellikler
- Threaded Mating Lock, Shield Connection Front Side
- Housing Material
- Polyamide
- Number Of Decks
- 1
- Kurşunsuz Kodu
- yes
- Montaj Tipi
- BOARD AND PANEL
- Akım
- 5A
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Front Panel Wire Connection
- Header, Female Sockets
