Volume pricing
- 1+ pcs$11.32
- 10+ pcs$10.68
- 100+ pcs$10.07
- 500+ pcs$9.50
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz Kodu
- yes
- Number Of Ways
- 4
- Pitch
- 0.400 10.16mm
- Flammability Rating
- UL94 V-0
- Orientation
- Right Angle
- RoHS Durumu
- RoHS Compliant
- Panel Thickness
- 0.039 ~ 0.118 1.0 ~ 3.0mm
- Safety Approval
- UL
- Weight
- 24.039999g
- Nominal Gerilim
- 1kV
- Seri
- COMBICON DFK-PC
- Max Current Rating
- 76A
- Uzunluk
- 76mm
- Pozisyon Sayısı
- 4
- Akım
- 66A
- Terminal
- Solder
- Rear Panel Wire Connection
- PCB Pins - Right Angle
- Number Of Decks
- 1
- Housing Material
- Polyamide
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 4 Weeks
- ECCN Kodu
- EAR99
- Özellikler
- Threaded Mating Lock, Shield Connection Front Side
- Gerilim
- 600V
- Akım Değeri
- 76A
- Genişlik
- 2.992 76.00mm
- Montaj Tipi
- BOARD AND PANEL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sıra Sayısı
- 1
- Panel Mount Type
- 2 Piece, Snap Lock - Front Flange
- Parça Durumu
- Active
- Yayın Yılı
- 2005
- Front Panel Wire Connection
- Header, Male Pins
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Contact Materials
- Silver
- Depth
- 46.4mm
- Renk
- Green
