Specifications
- Seri
- COMBICON FRONT
- Pitch
- 5mm
- Montaj
- Through Hole
- Parça Durumu
- Active
- Özellikler
- Interlocking (Side)
- Uzunluk
- 19.5mm
- Renk
- Green
- Max Current Rating
- 17.5A
- Additional Feature
- STANDARD: UL 94V-0, PA
- HTS Kodu
- 8536.90.40.00
- Contact Materials
- Tin
- Fabrika Tedarik Süresi
- 7 Weeks
- Mating Orientation
- Horizontal with Board
- RoHS Durumu
- RoHS Compliant
- Screw Thread
- M2.5
- Max Supply Voltage
- 250V
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Number Of Decks
- 1
- Wire Termination
- Screw - Pressure Clip
- Nominal Gerilim
- 400V
- Genişlik
- 25.5mm
- Radyasyon Dayanımı
- No
- Gerilim
- 300V
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polyamide (PA), Nylon
- Montaj Tipi
- Through Hole
- Sıra Sayısı
- 1
- Number Of Ways
- 1
- Wire Gauge Min
- 12 AWG
- Orientation
- Straight
- Safety Approval
- CSA; CUL; EAC; DNV; UL
- Wire Gauge Max
- 24 AWG
- Flammability Rating
- UL94 V-0
- Connector Type
- Screw
- Kurşunsuz Kodu
- yes
- Akım
- 17A
- Ambalaj
- Bulk
- Weight
- 3.559991g
- Wire Gauge
- 12-30 AWG
