Specifications
- HTS Kodu
- 8536.69.40.40
- Housing Color
- Grey
- Voltageiec
- 500V
- Weight
- 7.300002g
- Max Supply Voltage
- 500V
- Housing Material
- Polyamide
- Genişlik
- 6.2mm
- Kurşunsuz
- Lead Free
- Material Insulation
- Polyamide (PA), Nylon
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Awg
- 10-26 AWG
- Parça Durumu
- Active
- Montaj
- Through Hole
- Fabrika Tedarik Süresi
- 7 Weeks
- Uzunluk
- 28mm
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 500V
- Yayın Yılı
- 2012
- Kurşunsuz Kodu
- yes
- Depth
- 6.2mm
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- Not Applicable
- Akım Değeri
- 32A
- Renk
- Gray
- Sıra Sayısı
- 2
- Wire Gauge Min
- 10 AWG
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Material Flammability Rating
- UL94 V-0
- Akım
- 30A
- Tip
- Feed Through
- Stripping Length
- 8mm
- ECCN Kodu
- EAR99
- REACH Uyumluluk Kodu
- not_compliant
- Pitch
- 5mm
- Max Current Rating
- 32A
- Wire Gauge Max
- 26 AWG
- Terminal Stili
- Screw
- Gerilim
- 600V
- Seri
- CLIPLINE MBK
- Safety Approval
- UL; CSA
