Volume pricing
- 1+ pcs$2.43
- 10+ pcs$2.30
- 100+ pcs$2.17
- 500+ pcs$2.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Insulation
- Polyamide (PA), Nylon
- Connector Type
- Screw, Terminal Block
- Voltage Rated Dc
- 400V
- Wire Gauge Max
- 30 AWG
- Flammability Rating
- UL94 V-0
- Safety Approval
- UL; CSA
- Renk
- Gray
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 17.5A
- Akım
- 15A
- Genişlik
- 4.2mm
- Yayın Yılı
- 2006
- Housing Color
- Grey
- Wire Gauge Or Range Awg
- 14-30 AWG
- Reach Svhc
- No SVHC
- Orientation
- Straight
- Yükseklik
- 41mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Uzunluk
- 44mm
- Voltage Rated Ac
- 400V
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 4
- Housing Material
- Nylon
- Wirecable Gauge
- 26 AWG
- Weight
- 5.651988g
- Terminal Stili
- Screw
- Number Of Circuits
- 1
- Tip
- Feed Through
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- Not Applicable
- Max Current Rating
- 17.5A
- Kurşunsuz
- Lead Free
- Contact Materials
- Copper
- Wire Gauge Min
- 14 AWG
- Parça Durumu
- Active
- Number Of Decks
- 2
- Onay Kuruluşu
- CSA, UL
- Gerilim
- 300V
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
