Volume pricing
- 1+ pcs$7.03
- 10+ pcs$6.63
- 100+ pcs$6.26
- 500+ pcs$5.90
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Circuits
- 1
- Tip
- Feed Through
- Montaj
- Through Hole
- ECCN Kodu
- EAR99
- Depth
- 5.2mm
- Kurşunsuz
- Lead Free
- Max Current Rating
- 24A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Supply Voltage
- 500V
- Wire Gauge Min
- 24 AWG
- Nominal Gerilim
- 500V
- Parça Durumu
- Active
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Seri
- CLIPLINE MBKKB
- Number Of Levels
- 2
- Stripping Length
- 7mm
- Wire Gauge Max
- 24 AWG
- Material Insulation
- Polyamide (PA), Nylon
- Material Flammability Rating
- UL94 V-2
- Renk
- Gray
- Safety Approval
- UL
- Flammability Rating
- UL94 V-2
- Yayın Yılı
- 2013
- Akım Değeri
- 24A
- Genişlik
- 5.2mm
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Gauge Or Range Awg
- 12-24 AWG
- Sıra Sayısı
- 4
- Uzunluk
- 62mm
- Wirecable Gauge
- 12 AWG
- Housing Material
- Polyamide
- Weight
- 1.099961kg
- Terminal Stili
- Screw
