Volume pricing
- 1+ pcs$2.14
- 10+ pcs$2.02
- 100+ pcs$1.90
- 500+ pcs$1.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Stili
- Screw
- Weight
- 1.099961kg
- Housing Material
- Polyamide
- Wirecable Gauge
- 12 AWG
- Uzunluk
- 62mm
- Yükseklik
- 55.5mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Wire Gauge Or Range Awg
- 12-30 AWG
- Akım Değeri
- 24A
- Akım
- 20A
- Genişlik
- 5.2mm
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2008
- Renk
- Blue
- Safety Approval
- UL; CSA
- Flammability Rating
- UL94 V-2
- Material Flammability Rating
- UL94 V-2
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Max
- 30 AWG
- Number Of Levels
- 2
- Stripping Length
- 7mm
- Pitch
- 2.5mm
- Seri
- CLIPLINE MBKKB
- Wire Gauge Or Range Mm
- 0.2-4mm2
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- RoHS Compliant
- Onay Kuruluşu
- CSA, UL, cULus
- Parça Durumu
- Active
- Gerilim
- 300V
- Wire Gauge Min
- 12 AWG
- Nominal Gerilim
- 500V
- Max Current Rating
- 24A
- Number Of Poles
- 4
- Nem Hassasiyeti (MSL)
- Not Applicable
- Max Supply Voltage
- 500V
- Depth
- 5.2mm
- Montaj
- Cable
- ECCN Kodu
- EAR99
- Tip
- Feed Through
- Number Of Circuits
- 1
