Volume pricing
- 1+ pcs$0.61
- 10+ pcs$0.57
- 100+ pcs$0.54
- 500+ pcs$0.51
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Poles
- 2
- Pitch
- 6.2mm
- Sıra Sayısı
- 2
- Seri
- CLIPLINE MBK
- Gerilim
- 600V
- Akım
- 30A
- HTS Kodu
- 8536.69.40.40
- RoHS Durumu
- RoHS Compliant
- Montaj
- Through Hole
- Material Flammability Rating
- UL94 V-0
- Lead Pitch
- 6.2mm
- Wirecable Gauge
- 10 AWG
- Housing Material
- Polyamide
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 12 Weeks
- Onay Kuruluşu
- UL, cULus
- Uzunluk
- 28mm
- Orientation
- Straight
- Wire Gauge Max
- 26 AWG
- Weight
- 6.223996g
- Akım Değeri
- 32A
- Tip
- Feed Through
- Max Current Rating
- 41A
- Number Of Levels
- 1
- Yayın Yılı
- 2008
- Stripping Length
- 8mm
- Parça Durumu
- Active
- Genişlik
- 6.2mm
- Terminal Stili
- Screw
- Wire Gauge Min
- 10 AWG
- Flammability Rating
- UL94 V-0
- Kurşunsuz
- Lead Free
- Renk
- Gray
- Material Insulation
- Polyamide (PA), Nylon
- ECCN Kodu
- EAR99
- Voltageiec
- 500V
- Currentiec
- 32A
- Wire Gauge Or Range Awg
- 10-26 AWG
- Wire Gauge Or Range Mm
- 0.2-6mm2
- Ambalaj
- Bulk
