Specifications
- Stripping Length
- 7mm
- Weight
- 4.909996g
- Number Of Levels
- 1
- Genişlik
- 4.2mm
- Wire Gauge Max
- 30 AWG
- HTS Kodu
- 8536.69.40.40
- Parça Durumu
- Obsolete
- Akım
- 15A
- Seri
- CLIPLINE UK
- ECCN Kodu
- EAR99
- Tip
- Feed Through
- Kurşunsuz Kodu
- yes
- Renk
- Yellow
- Pozisyon Sayısı
- 2
- Gerilim
- 300V
- Material Flammability Rating
- UL94 V-2
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Min
- 14 AWG
- Terminal Stili
- Screw
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 500V
- Currentiec
- 17.5A
- Flammability Rating
- UL94 V-2
- Wire Gauge Or Range Awg
- 14-30 AWG
- Nem Hassasiyeti (MSL)
- Not Applicable
- Montaj
- Through Hole
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- REACH Uyumluluk Kodu
- unknown
