Volume pricing
- 1+ pcs$8.54
- 10+ pcs$8.06
- 100+ pcs$7.60
- 500+ pcs$7.17
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8536.69.40.40
- Flammability Rating
- UL94 V-2
- Nominal Gerilim
- 320V
- Rear Panel Wire Connection
- Quick Connect - 0.110 (2.80mm), Solder Eyelet
- Front Panel Wire Connection
- Header, Male Pins
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Pozisyon Sayısı
- 7
- Safety Approval
- CB; CCA; CSA; CUL; GOST; UL
- Orientation
- Straight
- Pitch
- 0.200 5.08mm
- ECCN Kodu
- EAR99
- REACH Uyumluluk Kodu
- unknown
- Max Current Rating
- 12A
- Number Of Ways
- 7
- Terminal
- Solder
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Panel Thickness
- 0.020 ~ 0.157 0.5 ~ 4.0mm
- Akım Değeri
- 12A
- Depth
- 29.5mm
- Uzunluk
- 55.88mm
- Montaj
- Wall
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 4 Weeks
- Seri
- COMBICON DFK-MSTB
- RoHS Durumu
- RoHS Compliant
- Genişlik
- 2.200 55.88mm
- Number Of Decks
- 1
- Additional Feature
- PA, UL 94V-2, SAFETY APPROVAL VDE
- Sıra Sayısı
- 1
- Panel Mount Type
- Screw Mount - Front Flange
- Housing Material
- Polyamide
- Akım
- 10A
- Contact Plating
- Tin
- Renk
- Green
- Gerilim
- 300V
- Wire Cross Section
- 2.5 mm2
