Volume pricing
- 1+ pcs$1.96
- 10+ pcs$1.85
- 100+ pcs$1.74
- 500+ pcs$1.65
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Materials
- Tin
- Housing Material
- Polyamide
- Akım
- 10A
- Gerilim
- 300V
- Renk
- Green
- Yükseklik
- 27.2mm
- Fabrika Tedarik Süresi
- 7 Weeks
- RoHS Durumu
- RoHS Compliant
- Seri
- COMBICON DFK-MSTB
- Number Of Decks
- 1
- Weight
- 3.960003g
- Genişlik
- 1.200 30.48mm
- Sıra Sayısı
- 1
- Panel Mount Type
- Screw Mount - Front Flange
- Connector Type
- Plug
- Number Of Ways
- 2
- Terminal
- Solder
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 12A
- Panel Thickness
- 0.020 ~ 0.157 0.5 ~ 4.0mm
- Parça Durumu
- Active
- Depth
- 29.5mm
- Uzunluk
- 30.48mm
- Montaj
- Wall
- Number Of Levels
- 1
- HTS Kodu
- 8536.69.40.40
- Kurşunsuz
- Lead Free
- Rear Panel Wire Connection
- Quick Connect - 0.110 (2.80mm), Solder Eyelet
- Flammability Rating
- UL94 V-2
- Nominal Gerilim
- 320V
- Front Panel Wire Connection
- Header, Male Pins
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Pozisyon Sayısı
- 2
- Safety Approval
- UL; CSA
- Orientation
- Straight
- Pitch
- 0.200 5.08mm
- ECCN Kodu
- EAR99
- Max Current Rating
- 12A
