Volume pricing
- 1+ pcs$5.65
- 10+ pcs$5.33
- 100+ pcs$5.03
- 500+ pcs$4.75
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Through Hole
- Number Of Circuits
- 2
- Parça Durumu
- Active
- Panel Thickness
- 0.039 ~ 0.236 1.0 ~ 6.0mm
- Akım Değeri
- 76A
- Uzunluk
- 63.6mm
- Wire Gauge Min
- 20 AWG
- Front Panel Wire Connection
- Bolt/Screw Clamp - Wire Entry 90° to Panel
- Material
- Polyamide
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- HTS Kodu
- 8536.69.40.40
- Nominal Gerilim
- 500V
- Flammability Rating
- UL94 V-0
- Wire Gauge
- 4-20 AWG
- Rear Panel Wire Connection
- Screw Terminal
- ECCN Kodu
- EAR99
- Max Current Rating
- 101A
- REACH Uyumluluk Kodu
- not_compliant
- Orientation
- Right Angle
- Wire Gauge Max
- 20 AWG
- Akım
- 85A
- Renk
- Green, Yellow
- Gerilim
- 600V
- Gender
- Female
- Genişlik
- 0.476 12.10mm
- Fabrika Tedarik Süresi
- 8 Weeks
- RoHS Durumu
- RoHS Compliant
- Seri
- CLIPLINE HDFKV
- Connector Type
- Screw
- Panel Mount Type
- 2 Piece
- Number Of Positions Per Level
- 1
