0709783

Specifications

Nominal Gerilim

500V

Flammability Rating

UL94 V-0

Rear Panel Wire Connection

Screw Terminal

Wire Gauge

4-20 AWG

HTS Kodu

8536.69.40.40

Terminal And Terminal Block Type

MODULAR TERMINAL BLOCK

Front Panel Wire Connection

Bolt/Screw Clamp - Wire Entry Parallel to Panel

Wire Gauge Max

20 AWG

REACH Uyumluluk Kodu

unknown

ECCN Kodu

EAR99

Nem Hassasiyeti (MSL)

1 (Unlimited)

Kurşunsuz Kodu

yes

Uzunluk

63.6mm

Wire Gauge Min

4 AWG

Panel Thickness

0.039 ~ 0.236 1.0 ~ 6.0mm

Parça Durumu

Active

Akım Değeri

76A

Montaj

Through Hole

Seri

CLIPLINE HDFKV

RoHS Durumu

RoHS Compliant

Fabrika Tedarik Süresi

4 Weeks

Additional Feature

POLYAMIDE

Genişlik

0.476 12.10mm

Weight

28.770003g

Panel Mount Type

2 Piece

Number Of Positions Per Level

1

Connector Type

Screw

Renk

Gray

Gerilim

600V

Wire Cross Section

25 mm2

Akım

85A
