Volume pricing
- 1+ pcs$10.47
- 10+ pcs$9.88
- 100+ pcs$9.32
- 500+ pcs$8.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Front Panel Wire Connection
- Bolt/Screw Clamp - Wire Entry 90° to Panel
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- HTS Kodu
- 8536.69.40.40
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 300V
- Rear Panel Wire Connection
- Bolt/Screw Clamp - Wire Entry 90° to Panel
- Wire Gauge
- 6-24 AWG
- ECCN Kodu
- EAR99
- Max Current Rating
- 76A
- REACH Uyumluluk Kodu
- not_compliant
- Wire Gauge Max
- 24 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Screw
- Positions Per Level
- 1
- Montaj
- Wall
- Parça Durumu
- Active
- Panel Thickness
- 0.039 ~ 0.157 1.0 ~ 4.0mm
- Akım Değeri
- 10A
- Wire Gauge Min
- 24 AWG
- Genişlik
- 0.398 10.10mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Seri
- CLIPLINE HDFK
- RoHS Durumu
- RoHS Compliant
- Panel Mount Type
- 2 Piece
- Akım
- 65A
- Renk
- Gray
- Gerilim
- 300V
