Volume pricing
- 1+ pcs$6.51
- 10+ pcs$6.14
- 100+ pcs$5.79
- 500+ pcs$5.46
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yükseklik
- 26.5mm
- Uzunluk
- 35mm
- HTS Kodu
- 8536.69.40.40
- Montaj
- Cable
- Seri
- CLIPLINE MSLKG
- Kurşunsuz
- Lead Free
- Weight
- 9.497997g
- Wire Gauge Or Range Awg
- 12-28 AWG
- Housing Color
- Green
- Flammability Rating
- UL94 V-2
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Tip
- Ground, Earth
- Number Of Decks
- 1
- Number Of Ways
- 2
- Sıra Sayısı
- 2
- Radyasyon Dayanımı
- No
- RoHS Durumu
- RoHS Compliant
- Material Insulation
- Polyamide (PA), Nylon
- Genişlik
- 7.5mm
- Orientation
- Right Angle
- Stripping Length
- 8mm
- Safety Approval
- ATEX; CSA; EACEX; IECEX; PRS
- Wire Gauge Max
- 24 AWG
- Terminal Stili
- Screw
- Parça Durumu
- Active
- Number Of Levels
- 1
- Wire Gauge Min
- 12 AWG
- Fabrika Tedarik Süresi
- 7 Weeks
- Kurşunsuz Kodu
- yes
- Depth
- 7.5mm
- ECCN Kodu
- EAR99
- Nominal Gerilim
- 6kV
- Housing Material
- Polyamide
- Renk
- Green, Yellow
- Material Flammability Rating
- UL94 V-2
