Volume pricing
- 1+ pcs$0.33
- 10+ pcs$0.31
- 100+ pcs$0.29
- 500+ pcs$0.28
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Width Outer Edges
- 0.310 7.87mm
- Studtab Size
- 8 Stud
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- Brazed Seam
- Material Insulation
- Vinyl
- Uzunluk
- 23.368mm
- Insulation
- Insulated
- Montaj
- Free Hanging
- Contact Materials
- Copper
- Insulation Diameter
- 0.170 (4.32mm)
- Terminal Type
- Circular
- Depth
- 7.9mm
- Renk
- Blue
- HTS Kodu
- 8536.90.40.00
- Wire Gauge Min
- 14 AWG
- Contact Plating
- Tin
- Nem Hassasiyeti (MSL)
- Not Applicable
- Thickness
- 0.032 0.81mm
- Length Overall
- 0.920 23.37mm
- Seri
- Pan-Term®
- Kurşunsuz Kodu
- yes
- Genişlik
- 7.87mm
- Safety Approval
- CSA; UL
- Radyasyon Dayanımı
- No
- Terminal
- Crimp
- Orientation
- Straight
- Wire Gauge Max
- 16 AWG
- Parça Durumu
- Active
- Yayın Yılı
- 2002
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge
- 14-16 AWG
- Ambalaj
- Bulk
- ECCN Kodu
- EAR99
- Terminal And Terminal Block Type
- RING TERMINAL
- Fabrika Tedarik Süresi
- 4 Weeks
