Volume pricing
- 1+ pcs$0.24
- 10+ pcs$0.23
- 100+ pcs$0.21
- 500+ pcs$0.20
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Bulk
- Wire Gauge
- 14-16 AWG
- Width Outer Edges
- 0.310 7.87mm
- Terminal
- Crimp
- Renk
- Blue
- Parça Durumu
- Active
- Montaj Tipi
- Free Hanging (In-Line)
- Radyasyon Dayanımı
- No
- Depth
- 7.9mm
- Terminal Gender
- FEMALE
- Length Overall
- 0.850 21.59mm
- Thickness
- 0.030 0.76mm
- Studtab Size
- 10 Stud
- HTS Kodu
- 8536.90.40.00
- Fabrika Tedarik Süresi
- 4 Weeks
- Material Insulation
- Polyamide (PA), Nylon
- Terminal And Terminal Block Type
- RING TERMINAL
- Wire Gauge Min
- 14 AWG
- Seri
- Pan-Term®
- Contact Plating
- Tin
- Nem Hassasiyeti (MSL)
- Not Applicable
- Contact Materials
- Copper
- Terminal Type
- Circular
- Montaj
- Free Hanging
- Yayın Yılı
- 2007
- Insulation Diameter
- 0.080 ~ 0.162 (2.03mm ~ 4.11mm)
- Orientation
- Straight
- Insulation
- Insulated
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Wire Gauge Max
- 16 AWG
- Uzunluk
- 21.59mm
- ECCN Kodu
- EAR99
