Specifications
- Length Overall
- 2.700 68.58mm
- Parça Durumu
- Active
- Terminal Type
- Rectangular Tongue
- Width Outer Edges
- 0.760 19.30mm
- Depth
- 19.3mm
- Contact Finish
- Electro-Tin
- Montaj Tipi
- Free Hanging (In-Line)
- Tab Thickness
- 0.120 3.05mm
- Wire Gauge Min
- 1 AWG
- Gender
- Female
- Terminal Style
- Two Stud Holes
- HTS Kodu
- 8536.90.40.00
- Renk
- Pink
- Body Plating
- Tin
- Wire Gauge Max
- 0 AWG
- Montaj
- Free Hanging
- Insulation
- Non-Insulated
- Diameter Ring Id
- 0.270 (6.86mm)
- Studtab Size
- 1/4 Stud
- Wire Gauge
- 1/0 AWG
- Ambalaj
- Bulk
- Contact Materials
- Copper
- Seri
- Pan-Lug®
- Diameter Barrel Od
- 0.520 (13.21mm)
- Fabrika Tedarik Süresi
- 4 Weeks
- Diameter Barrel Id
- 0.390 (9.91mm)
- Uzunluk
- 68.58mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Weight
- 385.553543g
- Terminal And Terminal Block Type
- RING TERMINAL
- Yayın Yılı
- 2004
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Radyasyon Dayanımı
- No
- Terminal
- Crimp, Barrel
