Specifications
- Terminal Style
- Two Stud Holes
- Renk
- Gray
- Width Outer Edges
- 0.620 15.75mm
- Diameter Barrel Id
- 0.280 (7.11mm)
- Terminal And Terminal Block Type
- WIRE TERMINAL
- Wirecable Gauge
- 4 AWG
- Terminal Type
- Rectangular Tongue
- Kurşunsuz Kodu
- yes
- Depth
- 15.7mm
- Length Overall
- 3.090 78.49mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Diameter Ring Id
- 0.410 (10.41mm)
- Montaj Tipi
- Free Hanging (In-Line)
- Terminal
- Crimp, Barrel
- RoHS Durumu
- ROHS3 Compliant
- Yayın Yılı
- 2005
- Radyasyon Dayanımı
- No
- Contact Finish
- Electro-Tin
- Terminal Gender
- FEMALE
- Body Plating
- Tin
- Parça Durumu
- Active
- Insulation
- Non-Insulated
- Contact Materials
- Copper
- Ambalaj
- Bulk
- Seri
- Pan-Lug®
- Diameter Barrel Od
- 0.380 (9.65mm)
- ECCN Kodu
- EAR99
- Wire Gauge
- 4 AWG
- Montaj
- Free Hanging
- Studtab Size
- 3/8 Stud
- Tab Thickness
- 0.080 2.03mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Uzunluk
- 78.486mm
- HTS Kodu
- 8536.90.40.00
