Specifications
- Diameter Barrel Od
- 1.060 (26.92mm)
- Ambalaj
- Bulk
- Seri
- Pan-Lug®
- Contact Materials
- Copper
- Insulation
- Non-Insulated
- Parça Durumu
- Active
- Terminal Gender
- FEMALE
- Body Plating
- Tin
- Contact Finish
- Electro-Tin
- Yayın Yılı
- 2004
- Radyasyon Dayanımı
- No
- RoHS Durumu
- ROHS3 Compliant
- HTS Kodu
- 8536.90.40.00
- Uzunluk
- 161.544mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Tab Thickness
- 0.220 5.59mm
- Studtab Size
- 1/2 Stud
- Montaj
- Free Hanging
- Wire Gauge
- 500MCM (kcmil)
- ECCN Kodu
- EAR99
- Wire Cross Section
- 253.3 mm2
- Terminal Style
- Two Stud Holes
- Terminal
- Crimp, Barrel
- Montaj Tipi
- Free Hanging (In-Line)
- Nem Hassasiyeti (MSL)
- Not Applicable
- Diameter Ring Id
- 0.530 (13.46mm)
- Length Overall
- 6.360 161.54mm
- Terminal Type
- Rectangular Tongue
- Depth
- 39.1mm
- Terminal And Terminal Block Type
- WIRE TERMINAL
- Diameter Barrel Id
- 0.840 (21.34mm)
- Renk
- Brown
- Width Outer Edges
- 1.540 39.12mm
