Specifications
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- Not Applicable
- Ambalaj
- Bulk
- HTS Kodu
- 8536.90.40.00
- Contact Finish
- Electro-Tin
- Terminal And Terminal Block Type
- RING TERMINAL
- Terminal Style
- Two Stud Holes
- Studtab Size
- 1/4 Stud
- Diameter Barrel Id
- 0.630 (16.00mm)
- Contact Materials
- Copper
- Body Plating
- Tin
- Radyasyon Dayanımı
- No
- Width Outer Edges
- 1.170 29.72mm
- Kurşunsuz Kodu
- yes
- Length Overall
- 3.600 91.44mm
- Terminal
- Crimp, Barrel
- Wire Gauge
- 4/0 AWG
- Renk
- Yellow
- Safety Approval
- CSA; UL
- Parça Durumu
- Obsolete
- Montaj Tipi
- Free Hanging (In-Line)
- Diameter Barrel Od
- 0.910 (23.11mm)
- Insulation
- Non-Insulated
- Seri
- Pan-Lug®
- Uzunluk
- 91.44mm
- Yayın Yılı
- 2004
- Montaj
- Free Hanging
- Terminal Type
- Rectangular Tongue
- Tab Thickness
- 0.140 3.56mm
- Diameter Ring Id
- 0.270 (6.86mm)
- Depth
- 29.7mm
- Fabrika Tedarik Süresi
- 4 Weeks
- ECCN Kodu
- EAR99
